Notifier by Honeywell NFXI-TDIFF Addressable Heat Detector + B501AP Base

Name: Notifier by Honeywell NFXI-TDIFF Addressable Heat Detector + B501AP Base
SKU: fs05023094
Availability: InStock

AED 787.50 VAT included

Compare

Product Code : fs05023094 Seller: Approved by : [woo_pro_badges_extended]

free delivery

Above AED1000 in Dubai
WARRANTY

For 365 days
always authentic

Only Reputed Brands
EASY PAYMENT

Multiple payment options

Description

Notifier by Honeywell NFXI-TDIFF Addressable Heat Detector + B501AP Base are fixed temperature analog addressable sensors employing low mass thermistors and microprocessor technology for fast response and linear temperature sensing. Their linear response allows these sensors to be used to signal temperatures over the range of 58°C (Class A1S) to 78°C (Class BS).

Features

New advanced Opal protocol allows mapping of the loop for precise fault location using isolators
100% mechanical and electrical backwards compatibility
Tri colour LED offering red, green and amber colours
Pure white colour to complement modern buildings
Base designed to ease installation and wiring
Rotary decade address switches
Built in short circuit isolation

Specifications

Product: Addressable Heat Detector
Brand: Notifier By Honeywell
Model: NFXI-TDIFF + B501AP
Operating Voltage Range: 15 to 28.5Vdc
Maximum Continuous Current: 1A (switch closed)
Material: PC/ABS
Colour: White
Max Wire Gauge for Terminals: 2.5mm2
IP Rating: IP40 when installed in B501AP base; IP43 when installed in WB-1AP base
Weight: 97g (inc base)
