HONEYWELL UNIPOINT CONTROLLER (MV) 2306B2000 x 4+ PLC enclosure + Power supply

Name: HONEYWELL UNIPOINT CONTROLLER (MV) 2306B2000 x 4+ PLC enclosure + Power supply
SKU: fs050648
Availability: InStock

AED 9,450.00 VAT included

Compare

Product Code : fs050648 Seller: Approved by : [woo_pro_badges_extended]

free delivery

Above AED1000 in Dubai
WARRANTY

For 365 days
always authentic

Only Reputed Brands
EASY PAYMENT

Multiple payment options

Description

HONEYWELL UNIPOINT CONTROLLER (MV) 2306B2000 x 4+ PLC enclosure + Power supply can be easily installed into any plastic or metal enclosure for use indoor or outdoors and even in potentially explosive atmospheres. With the addition of one of Honeywell Analytics’ range of flammable, toxic or Oxygen detectors, systems may be configured to monitor gases in a wide range of applications from car parks and boiler houses to analyser shelters or crane cabs in offshore facilities.

Features

Relays configurable as energized, de-energized, latching or non-latching, alarm relay on/off delay
Fully user programmable scale, units and calibration
3 wire mV bridge, 2 and 3 wire 4-20mA inputs
Compatible with a wide range of gas detectors
User friendly with ultra-clear backlit display
TS35 (‘top hat’) DIN rail mounting
Removable terminal connectors
Simple pushbutton operation
Easy access to all terminals
Ultra-clear backlit display

Specifications

Product: Gas Detection Controller
Brand: Honeywell
Part No: 2306B2000
Supply: Nominal 24VDC (18-32VDC). Max power mV = 4.8W (including power to detector), mA= 3.0W (excluding power to 3 wire detector)
Electrical Safety: EN61010, UL61010b
Operating Pressure Range: 90-110kPa
Backlit Display: Units of measure, digital gas reading and event code
IP Rating: Indoor, IP3x, to BS EN 60529:1992 (controller to be installed in suitable enclosure)
Weight: 225g (7.94oz) - Controller only
