Hochiki CHQ-DZM/DIN(SCI) Dual Zone Monitor – Din Enclosure with SCI

Name: Hochiki CHQ-DZM/DIN(SCI) Dual Zone Monitor - Din Enclosure with SCI
SKU: fs108513
Availability: InStock

See all products from hochiki

AED 640.50 VAT included

Model CHQ-DZM/DIN(SCI) is a Dual Circuit Zone Controller designed to allow up to 60 conventional detectors (30 on each zone) to be interfaced to Hochiki’s ESP analogue addressable system. The unit also features a Schottky Diode line continuity option, when used inconjunction with the optional LCMU.

Compare

Product Code : fs108513 Brand: Hochiki Seller: Fireshop1001 Approved by : [woo_pro_badges_extended]

free delivery

Above AED1000 in Dubai
WARRANTY

For 365 days
always authentic

Only Reputed Brands
EASY PAYMENT

Multiple payment options

Description

Full monitoring against malfunction or disconnection, together with a self-test feature through the ESP protocol, ensure the integrity of the CHQ-DZM/DIN(SCI) at all times. The unit utilises simple DIL switches for reliable addressing. It is also available as a boxed module (CHQ-DZM(SCI)). Both models feature an integral short-circuit isolator.

Features

Single loop address
Supports two independent zones of conventional detectors
Both zones fully monitored for short/open circuit
Requires an auxiliary 24 VDC supply
Also available as a boxed module
Both models feature an integral short-circuit isolator
Approved by LPCB

Specifications

Brand: Hochiki
Current Consumption: (Quiescent) 2 mA, (Alarm) 70 mA (both zones in fire
Current in Short Circuit: 8 mA
Dimensions: L=157 x W=127 x D=35 (CHQ Module plus Lid) D=79 (CHQ Module plus Lid plus CHQ - BACKBOX) (add 235 to module weight when using CHQ-BACKBOX)L108 x W119 x D24 (CHQ DIN Module)
Low Power Mode: 110 A
Maximum Short Circuit Current: 1 A
Operating Temperature: -10 °C to +50 °C
Operating Voltage: 17 - 41 Vdc
Quiescent Current: 330 A
Storage Temperature: -30 °C to +60 °C
Weight: 130g
