Asenware AW-FP300 Fire Alarm Control Panel

Name: Asenware AW-FP300 Fire Alarm Control Panel
SKU: fs1118335
Availability: InStock

See all products from asenware

AED 3,281.25 VAT included

Compare

Product Code : fs1118335 Brand: Asenware Seller: Approved by : [woo_pro_badges_extended]

free delivery

Above AED1000 in Dubai
WARRANTY

For 365 days
always authentic

Only Reputed Brands
EASY PAYMENT

Multiple payment options

Description

Asenware AW-FP300 Fire Alarm Control Panel (FACP) is to monitor input signals, give indications and possibly activate outputs as programmed. It is designed to comply with EN 54-2 with qualities of simple installation, operation, and easy maintenance. The AW-FP300 panel is an addressable fire detection panel with 1 loop of 324 addressable points and expansion capabilities. It is compatible with other peripherals made by ASENWARE with its own protocol.

Features

AW-FP300 single loop 32 zone fire alarm control panel offers Up to 324 addresses on one loop
An easy to read, 4.3'' color screen LCD with a resolution of 480×272
Zone indication and control panel(ZCP) for 32 zones gives a quick indication of the location of an alarm
Record capacity of 1000 historical events for each of historical fire, historical fault and historical operation
An independently programmable conventional sounder circuit output
Flexible and intuitive cause and effect programming on front panel
Zone test, point test and module start/stop testing facilitate the commissioning
U-disk interface makes the load and save of configuration or historical data convenient for system commissioning and maintenance
Integral power supply and battery
Hierarchy management with three access levels

Specifications

Product: Addressable Fire Alarm Control Panel
Brand: asenware
Model: AW-FP300
Mains supply: 230VAC (-15%, +10%). 47 ~ 63Hz. Max current 0.8A
Operating voltage: 18.5 ~ 30VDC
Max. charging current: 1.2A
Max. battery supply current: 4A (when the Mains is disconnected)
Recommended battery cable: 14AWG
Recommended type of cable: Plain unscreened cable, 1.5mm2
Temperature range: 0°C~45°C; Max relative humidity: 95% (40°C ±2°C, no condensation)
